Krenule su spekulacije:
Q3 listing HD6750, 40nm process, the chip area of more than Cypress, less than 400 mm2, still 1600SP/256bit bit wide, divided into two 800SP modules, each of which has an enhanced off Tessellation Unit and a Rasterizer, two modules parallel-oriented graphics. Triangles rate doubled, Tessellation 3-4 times performance improvement. L2 Cache redesigned to significantly improve the performance of GPGPU. Core frequency of 900Mhz-1GHz, TDP of 225 watts or so. Target performance is 10% -20%, GTX480, expectations and GF100 B1 version of its flagship chip, the performance was flat. North Island family, the first product in the maturity process of verifying the new structure.
Q4-Q1 next year, listing HD6670/6650, single 800SP modules / 128bit bit width, Water 28nm process.
Q1-Q2 next year, listing HD6870, 28nm process, four 800SP module, 512bit-bit wide return to core area of 400-450 mm between the target performance of dual-core card Fermi suppression. In fact, R600 is the ultimate form
